XFL500 Automatic Extension Milling Head
1.European OEM’s spindle clamping is about 2~3 times stronger than conventional ISO four pull bolt on clamping force.
2. A design of ultra-short butt spindle clamping height supported by a super-large curvic coupling reinforces heavy cutting torque.
3. A new type of angle indexing curvic coupling with loose-proof design avoids gear disengagement when insufficient clamping pressure happens.
4.Equipped with the feature of automatic clamping and automatic tool change, enhancing machining efficiency and production flexibility.
5.Coolant jets around the spindle ensures accurate cutting fluid supply.
6.Spindle air curtain protection technology effectively prevents dust and chips from entering, extending spindle life and improving stability.
Inquiry Now
| Item \ Model | XFL500 |
| Spindle Type | BBT 50 |
| Max. Speed | 4000RPM |
| Max. Toruqe | 800N.m |
| Max. Horsepower | 35kw |
| Reduction Ratio | 1:1 |
| Max. Tool Diameter | Ø150(6") |
| Spindle Rotation | Clockwise (Tapping work allows clockwise and anticlockwise) |
| Clamping Force | approximately 1.5T |
